Applicable fields:
Advertising industry, decoration, furniture, model manufacturing, and handicraft industry. The machine is widely applied in the fine engraving, cutting and hollowing out on nonmetallic materials. With all kinds of characters, graphs, images, trademarks and so on.
Available Materials
Acrylic, organic board, double color plate, plank, bamboo product, paper, glass etc.
Technical Information
| Technical Index |
Technical Parameter |
Memo
(Buyer’s option) |
Model |
SCK1060 |
|
Working platform size |
1000*600mm |
|
Power |
Co2 80/100W(Chinese Tube) |
75W/100W RF laser tube (imported from U.S.A) |
Controlling system |
PCI |
USB |
Software |
DSP |
|
Support format |
PLT, BMP, DXF, DST, T100, etc |
|
Process Material |
Non-metal Materials |
|
Cutting speed |
≤500mm/s |
The machine can fix servo-motor to improve the movement performance |
Engraving speed |
≤1000mm/s |
Repeated accuracy |
≤±0.025mm |
Min. cutting character |
0.1mm |
Max. cutting depth |
0-25mm(it’s up to the material) |
|
Cooling ways |
circulation of water cooling |
|
Working temperature |
0-35°C |
|
Working humidity |
5-95% |
|
Working Power |
220V/50Hz/1kVA |
|
Dimension |
1670*1450*1280 mm |
|
Net weight |
399kg |
|
Cubage |
3.09CMB |
|
Package |
Standard Crate for export |
|
The whole machine include |
Air pump |
|
| Exhausting Fan |
|
| Cooling water box |
|
Other included |
Accessory box (Including PCI card, Microsoft dog, tools, pipes, quality certification etc.) |
|
Minimum Order Quantity |
1 Set |
|
Product Introduction: Sunic Photoelectricity has been bringing forth new innovations in laser technology constantly and now have more than 30 various laser machines for a variety on industries such as solar equipment, laser scribing machine, laser marking, pneumatic marking machine, laser cutting machine, laser engraving machine and so on. Our laser experience has enabled us to greatly revolutionize industries in the fields of solar energy, electron, leather clothing, advertising, craftwork, automobile motorcycle, hardware, tools, measuring and cutting tool, hot-water heating, cleaners and polishes, food beverage and medicine, medical treatment, seal, printing, engraving and packing industry, upholster etc.
Service Network: Sales of laser scribing machines has exceeded 85% of the local market. It is the appointed products of the foreign-aid project of national Commission of Foreign Trade and Economic Cooperation. Sunic Photoelectricity has more than 40 international distributors as well as offices all over mainland China. Currently we have branches in Dongguan, Guangdong Province. Our product is also exported to U. S. A, Japan, South Korea, South Africa and Southeast Asia, Taiwan, Hong Kong, Australia etc. This is evidence of the pride we take in our products and services as we move forward into future advancements in laser technology.
