*More accurate procession
Integral cast-iron Rolling ball screw from Germany and tri-bearings for positioning to ensure much high precision
*Advanced system
Advanced IC designing to realize more precision calculation and high speed transmitting of data;
Compatible with Type3/Artcam/Casmate/CAXA/antgrave,etc.
*Perfect structure
Adopt structure of industrial tool machines with integral iron frame, equipped with embedded guiding track transmission and lager power spindle motor.
|
Model
|
SW300B
|
SW900
|
SW1200
|
SW1800
|
SW2500
|
SW3000
|
|
Working Area
|
300*250* 40mm
|
650*900*90
mm
|
1200*1200*90
mm
|
1800*1800*90
mm
|
1300*2500*90
mm
|
2000*3000*90
mm
|
|
Spindle Motor
|
1.5KW constant power spindle motor cooled by water
|
2.2KW constant power spindle motor cooled by water
|
|
Motion Speed
|
3000-8000mm/min
|
|
Rotating Speed Of Spindle
|
6000-24000rpm
|
|
Engraving Tools
|
3.175 , 4, 6,12.7mm(optional)
|
|
Dictate Format
|
HPGL,G-code
|
|
Resolution
|
0.01mm
|
Convenient operation
Restore from power off, continuation, anticipate working time, auto-feeding blades, friendly designing.
Dust Collecting System (optional)
Vacuum System (optional)
Power spindle motor can be mounted as requested
Servo system (optional)
