Specification:
1. CE&FDA
2. Lifting platform
3. Water cooling and no water warning
4. 60W/80W
5. Optional imported RF laser
6. Customer design will be OK.
Technical parameters:
| Model |
YH-G8050 |
| Laser type |
Sealed CO2 glass laser tube |
| Laser power |
50W/60W |
| Engraving area |
720×500mm |
| Cutting area |
750×500mm |
| Appearance size |
1170×1160×885mm |
| Engraving speed |
0~1200mm/s |
| Cutting speed |
0~300mm/s |
| Cutting thickness |
0~8mm |
| Positioning precision |
±0.01mm |
|
Characters
|
1.5mm English letter |
| Format support |
AI,BMP,PLT,DXF,DST etc. |
| Power supply |
AC220V±5%/50HZ~60HZ |
| Power of machine |
≤900W |
Product features:
- Professonal design ideas,customized for the users in different industries,elegant appearance and appliance.
- LED ,USB 2.0 offline card, 128M memory space.
- Professional move control system,adopts advanced three-phase step motor and transmission system in high speed and precision.
- The laser power supply has the excusive self-protection setting,ensure the stability and safety of the machine to the highest degree. Electronic control lift platform,convenient to feed the material in back and forth, easy and felxible to operate can engrave materials with different height.
- Adopt the aviation light path system, imported linear guide rail, to guarantee the smoothness of the light knife moving and high engraving precision.
- (Optinal) Auxiliary rotary device: Process the cylinder object and break through the engraving limit of 2-dimenision.
Applicable materials:
Wood, paper, leather, cloth, Plexiglas, epoxy resin, density board, double-colored board, marble, plastic, rubber, ceramic tile, crystal, bamboo and other nonmetal materials.
Installation and training
1.Without sending engineer
Manual and video will be sent to you for training and learning how to install machine.
Internet remove assistance is available 24hs everyday.
2.With engineer
Engineer will be sent to your country for one week, dealing with the installation and training.
User need to take care of tickets, accommodation, food and cooperating with the engineer we dispatch.
3. If you are here
you got 5 days for free training, if you are in our factory. We will learn you any basic information about the machine
Samples:
