China new advertising engraving machine high power long lifetime
Facebook Twitter Delicious Google Email this page
Product Details:
Model:
CX1313,CX1318,CX1325
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Set/Sets
Place of Origin:
Min. Order:
120
FOB Price:
USD 0.00-0.00 /Set
Shippment Port:
qingdao
Payment Terms:
L/C ,T/T
Show Buyers your Ability to Supply:
Production Capacity:
100 Set/Sets
Delivery Time:
Month
Packaging:
wooden case
Female. Yang Lele



Send a Message to this Supplier

Product Details Company Profile



China new advertising engraving machine high power long lifetime



feature:

1.The spindle are controlled by software,high automization.

2.High spindle and high efficiency,idle speed can reach up to 8.8 meters/min.

3.High power frequency water cooling spindle,main part  are all imported,low noise,high power,long lifetime.

4.Double motors driving,high driving force,unique two-rack axises transmission ,so it can gusrantee no distortion and vibration when it works for long time.





model

1313

1318

1325

X working area

>1200mm

 >1200mm

 >1200mm

Y working area

 >1300 mm

 >1800mm

 >2400mm

Z working area

 100mm

  100mm

  80mm

table size

 1400mm*1680mm

 1400mm*2280mm

 1400mm*2880mm

traveling positioning accuracy

 0.05mm

 0.05mm

 0.05mm

repositioning positioning accuracy

 0.02mm

 0.02mm

 0.02mm

table  structure

 aluminum

 aluminum

 aluminum

X,Y,Z structure

 X,Y,Z ball screw

 X,Y,Z ball screw

 X,Y,Z ball screw

max.power consumption(without spindle)

 0.8kw

 0.8kw

 0.8kw

max.rapid travel rate

 10000mm/min

 6000mm/min

6000mm/min

max.working speed

 3000mm/min

3000mm/min

 3000mm/min

spindle power motor

 1.5kw

 1.5kw

1.5kw

spindle speed

 0-24000r/min

 0-24000r/min

0-24000r/min

drive system

 stepper

 stepper

stepper

working voltage

 AC220V/50HZ

 AC220V/50HZ

 AC220V/50HZ

command language

 G code

 G code

 G code

operating system

DSP controlling

DSP controlling

 DSP controlling
