3.2m Double Side Printer
Facebook Twitter Delicious Google Email this page
Product Details:
Model:
MT-starjet 77802L
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Set/Sets
Place of Origin:
Min. Order:
120
FOB Price:
0.00-0.00 /
Shippment Port:
Payment Terms:
T/T,Western Union
Show Buyers your Ability to Supply:
Production Capacity:
0
Delivery Time:
Packaging:
Ms. Rao Helen



Send a Message to this Supplier

Product Details Company Profile

With multiple high precision cameras, the advanced new algorithm on real time tracking calculation, perfectly take over the reverse side print jobs as accurate as below millimeter distortion even in 320cm (10.5ft) print width.

Moreover, seven calibration reference points on iPrint Console software for the pre-correction to different medias bring the ultimate fine tune in every which factors of the print job



The detachable media handling systems can swap around the printer as feeder and take-up which make the double side print jobs light and easier.

Time is Money!” is the golden rule to every print shop. *With 52sqm/hr/side print speed and high production yield rate. The MT-starjet 77802 can bring you not only the quality but also productivity to beat the unbeatable barriers.



***Color and Size Do Matters !!

It’s more and more hard to get people’s attraction in the sea of advertising signs. An ultimate weapon to provide the best print quality on Indoor/Outdoor backlit sign making, without limitation on size, color and resolution, the last obstacle need to breakthrough to win people’s attraction will be art designers’ imagination.MT-starjet 77802 can print vivid color in photo quality without size limitation on post-production by using relatively low cost flex banner

***New Flagship of MT-starjet Family

With our tradition on innovation. MT-starjet77802 has no doubt becomes to MT-starjet flagship to lead the signage markets to the new era. Easy-to-operate user interface, caster feeder/take-up and high print speed in photo quality. Nevertheless, reasonable price bring all these features to benefit your business and win the markets. The MT-starjet 77802L with the maximum print width of 320cm can make the large size outdoor backlit light box becomes to a simple task.

***Low Profile Luxury

Printer in whole black color mounted with LED checking bar in front of the post heating platform.

New designed feeder/take-up with power & torque control.

Secondly upper feeder makes the light media such as adhesive vinyl easy to handle.

High Speed 2-Pass printing to satisfy both speed and quality.

Unique design to print front & reverse side in different passes to increase the printing performance.

Maintenance free cameras to track the reverse side printing all the time.

Intelligent double side print control software with auto labeling to eliminate any possible human error.

Two powerful DX7 print heads reach total of 2880 print nozzles to deliver 2” (inches) per pass print height, 12%~15% faster compare to MT-starjet DX5 head printer.

Proprietary installment soft key option to extend your business opportunities

Variable ink droplet control technology to bring up maximum print quality and performance.





MT-starjet77802L

MT-starjet 77802

Print Head

Two DX7 Drop-on-demand Micro-Piezo Print Heads

Number of Nozzles

2880 Nozzles (2 Heads)

Color

4 ColorsCyan, Magenta, Yellow, Black

Resolution

1440dpi (max)

Height of Print Head

2-5mm

Size of Ink Droplet

1.5-21 pl

Max. Print Width

3200mm

1800mm

Max. Media Width

3300mm (max)

1900mm (max)

Real Time Tracking

4 Cameras

3 Cameras

Print Speed

2 pass: 52 sqm/hour/side

2 pass: 49 sqm/hour/side

4 pass: 28 sqm/hour/side

4 pass: 25 sqm/hour/side

Media Feeder

Yes

Media Take-up

Yes

Media Payload

200kgs (max)

70kgs (max)

Heating System

Print heater and Post heater with PID temperature control

Ink

T5.5 eco-solvent ink

Ink Cartridge

8 Cartridges

RIP Software

iPrint 3.0

Control Software

iPrint Console (installment version as option)

Operation System

MS Windows XP & Windows 7

Interface

USB port ver. 2.0

Power Voltage

110-120V or 220-240VAC; 50-60Hz

Printing Environment

Temperature: 20-26°C, Humidity: RH40-60%

Printer Dimension

W4300*D900 * H1250mm

W2840*D900*H1250mm

Packing Dimension

W4350*D930 * H730mm

W2920*D930*H730mm

Net Weight

320kgs

240KGS

Gross Weight

550kgs

380KGS
