| Model: |
M10 |
| Print Technology: |
Drop-on-demand Piezo Electric |
| Printhead Type: |
JAPAN KM1024MHB-14PL |
| Printhead No.: |
4/5/6/7/8/10/12pcs |
| Printhead Controls: |
Print head temperature & voltage are adjustable by software |
| Printing Size: |
205cm x 320cm |
| Ink Characteristics: |
UV curing ink |
| Ink Reservoir: |
Refillable on the fly while printing/1000ml |
| Loating Mode: |
Resto/Servo |
| RIP Software: |
Photoprint10 /ONYX /Caldera |
| Drying System: |
UK Integration uv lamp |
| File Format: |
TIFF, JPEG, Postscript 3, EPS, PDF, and so on. |
| Resolution: |
360 dpi x 360 dpi 360 dpi x 720 dpi |
| |
720 dpi x 360 dpi 720 dpi x 720 dpi |
| |
720 dpi x 1440 dpi 1440 dpi x 1440 dpi |
| Printing Speed: |
In draft mode up than 60sq.m |
| |
In standard mode up than 30sq.m |
| |
In high resolution mode up than 15sq.m |
| Ink Type: |
UV curing ink |
| Ink Color: |
4 colors (C, M, Y, K) - 8 colors (C,M,Y,K,LC,LM+White+Varnish) |
| Printing Materials: |
Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc. |
| Heating System: |
Standard (Front heater, Rear heater, Fan) |
| Color Retains: |
Outdoor 2 years, indoor 10 years |
| Color Management: |
ICC based color, adjustment curves, density adjustment |
| Power Supply: |
AC220V 50/60HZ (10%) 16A |
| Working Conditions: |
Temperature 20-28 degrees, Humidity 40% - 60% |
| Dimensions: |
4.8m*3.93m*1.38m |
| Weight: |
2160kgs |
| Packing: |
Packed by solid wooden carton. |
