Techincal Parameter
|
MDF Laser cutting machine Technical Specifications
|
|
Model
|
JQ1325
|
|
Cutting area
|
1300x2500mm
|
|
Laser power
|
60W 150w
|
|
Laser type
|
CO2 sealed laser tube,water-cooled,10.6um
|
|
Cutting speed
|
0-50000mm/min
|
|
Laser Output
|
1-100%software setting
|
|
Resetting positioning accuracy
|
≤±0.01mm
|
|
Power supply
|
AC 110 - 220V ± 10%, 50 - 60Hz
|
|
Operating temperature
|
0 - 45°C
|
|
Operating humidity
|
5 - 95%
|
|
Min. shaping character
|
English 1.0mm x 1.0mm
|
|
Graphic format supported
|
BMP, PLT, DST, DXF, AI
|
|
Software supported
|
Tajima,CorelDraw, PhotoShop, AutoCAD
|
|
Driving system
|
Cutting dedicated Stepper
|
|
Cooling mode
|
Water-cooling and protection system
|
|
Equipment Dimensions
|
3180x1980x1120mm
|
|
Net Weight:
|
1100kg
|
|
Optional Spare Parts
|
USB , Honeycomb table, red light pointer , up-down worktable
Rotary attachment,
|
|
Recommended Spare Parts
|
Laser Tube and Lens
|
Applicable Industries
Model Industry(construction models,aviation and navigetion models and wooden toys),advertisement,decoration,art crafts,electronics,and electric appliances,etc.
Applicable Materials
Non-metal materials such as acrylic, painted metal , organic glass , wood planks(light planks) , bamboo ware , double-color boards , paper , leather , shells , coconut shells , ox-horns , resin animal grease , ABS boards , lamp shade , ect.
