Character Features
◆Professionally Integrated circuit with high precision and high speed
◆In time regulation on speed and force, setup the origin point at discretion
◆Advanced aluminum alloying structure excellent workmanship, long used life and durability
◆Supporting various of popular software on the market.
◆Origin imported high speed stepping motor, low noise, cutting more precisely
◆Unique blade soft landing function, easy for cutting
◆Compatible with many computer operation systems such as Windows XP,Vista,Windows7 (32bit&64bit)
Technical parameter(Economical Type)
|
Model Item
|
JK360
|
JK720
|
JK870
|
JK361
|
JK721
|
JK871
|
JK1101
|
JK1351
|
|
Max. Paper Width
|
360mm
|
720mm
|
870mm
|
360mm
|
720mm
|
870mm
|
1100mm
|
1350mm
|
|
Max. Plotting Width
|
270mm
|
630mm
|
780mm
|
270mm
|
630mm
|
780mm
|
1000mm
|
1260mm
|
|
Memory
|
1M
|
1M
|
1M
|
1-4M
|
1-4M
|
1-4M
|
1-4M
|
1-4M
|
|
Net Weight/Gross Weight
|
9/10kgs
|
11/20kgs
|
12/22kgs
|
8/12kgs
|
11/20kgs
|
12/22kgs
|
14/26kgs
|
17/31kgs
|
|
Packing Size
|
60*34*39cm
|
95*34*43cm
|
110*34*43cm
|
60*34*39cm
|
95*34*43cm
|
110*34*43cm
|
133*34*43cm
|
158*34*43cm
|
|
Max. Plotting Speed
|
500mm/s
|
|
Max. Cutting Force
|
400g
|
|
Mechanical Resolution
|
0.0254mm
|
|
Interface
|
COM
|
COM, USB & LPT (optional)
|
|
Power Supply
|
Transformer
|
Switching power supply
|
|
Stand
|
No
|
Optional
|
Optiona
|
No
|
yes
|
yes
|
yes
|
yes
|
|
Colors
|
White Color, Grey Color, Black Color
|
|
|
|
|
|
|
|
|
|
|
|
